Here we will discuss the major points when looking for a solution for how to tune a bow.
Monitoring the Maximum Poundage– When pulling the bow to its greatest draw force, you can verify if it is within the company’s standards. After you’ve turned the limb nuts back down, you’ll need to check the axle to axle, bracing height, and full length. If any of the measures differ from the standards of the company, the controlling cables, buss cables, or drawstring will need to be adjusted. At this point, you must also ensure that the bow is reaching the maximum poundage. It’s fine if it’s a little over and no more than 2-3 pounds.
Measurement Tiller– Once the bow has been returned to the maker’s standards, you can make appropriate modifications to the poundage of the legs. Most limbs have max adaptability of ten pounds. In general, every circular rotation will weigh two pounds. When changing the draw weight, ensure the tiller lengths on both the upper and bottom limbs are equivalent. The tiller is set 90 degrees out from the limb compartment to the string. Before performing any load adjustments, make sure all securing bolts are unfastened. These nuts can be located on both sides of the limb compartments. Avoid extending the limbs beyond the owner’s manual.
Cam Lean– Establish Cam Lean by positioning an indicator flush with the upper and bottom cams. Attempt to get the arrow exactly perpendicular to the string. To do this, a bow press would be required to reduce or extend the buss cable yokes. Because binary cams lack a yoke mechanism, shimming is required. Shimming is a time-consuming process that should be handled by the manufacturer as required.
Nock Height- To use a T-Square, utilize the edge with the number “0” perfectly in line with the T-edge. Tie your D Loop immediately, and don’t let it go! Many bows require a 1/8th-inch nock height, which you will attain by lowering your rest.
Rest Height– When your D-Loop is in position and secured, install your arrow rest. Set your rest with an archer leveling such that your bow is a 1/8th extra inch to begin, and make any necessary vertical changes when firing through paper.
Center Shot– Ask your bow manufacturer if there is a suggested center shot size. If they do, check inside the riser to the arrow’s center to obtain your starting center shot. You may also use a light center aim tool to align the thread with the direction of the arrow. Another approach is to place an arrow inside the shaft. Set the bow rest so that the nocked arrow is level with the riser arrow.
Cam Timing– Set the draw limits to the location that corresponds to the module’s draw duration. Before trying to modify the draw strength of your bow, always consult the manufacturer’s instructions. At full draw, some bows use pull stops that contact the cables, while others use to draw “Stops” that communicate directly with the limbs. Bend the bus cable or control cable one at a time to move the cam until it is perfectly timed.
Paper Tuning– Once you’ve determined the right D-Loop position, center shot and returned the bow to the manufacturer’s specs, you can begin paper tuning. For fine-tuning adjustments, see the paper tuning guide below.
Yoke Tuning– The top yoke of a hybrid or single-cam bow will do need to be adjusted. If your arrow has a right nock tear, twist the right yoke and shoot through the paper again. Once the bottom has been “zeroed out,” make the appropriate modifications to the upper yokes to produce the desired horizontal tear.
Paper Tuning – Walk back tuning provides that arrow a direction, which provides the arrow the essential direction to fly in a single direction from one yard out to 60 yards. For more details on walk-back adjustment, watch the Agony Outdoor Youtube clip titled “Walk Around Tuning.”
What is the correct method for modifying a bow yoke?
To modify the yoke, squeeze the bow and release the control cable tension. By pressing the bows, we ought to remove the controlling cable from the bow’s top wheel pin. After detaching the yoke, twist or untwist either side of the yoke to obtain appropriate alignment at full pull.
What exactly is a bow tune-up?
Sellers can alter the draw strength and length of a bow to suit the archer. Adjusting a bow entails adjusting the arrow’s rest, arrows, cam location, and cam timing. A bow could be correctly set up and in the specification but can also be out of tune.
How far away should you sheet tune a bow?
At a range of 4 to 6 feet, shoot arrows into a hanging sheet of paper and notice the resultant split.
